    מד מפלס NBK-04

    מד מפלס מסוג Bypass התקנה עליונה


    אורך מקסימאלי 4000 מ"מ


    מבנה: נירוסטה 316L


    טמפרטורה מקסימאלית:  עד C °120


    אוגנים:  DN65 , DN50


    אופציה:  מגעים יבשים לפיקוד,יציאה אנלוגית,


    תצוגה דיגיטאלית


     אטימות:  65 IP


    nbk






    The KOBOLD Model NBK-04 tank-top mounted level indicator combines the rugged simplicity of our NBK series bypass level indicators with above-tank liquid level indication. These level indicators are used for continuous indication, transmission and monitoring of tank levels. A sealed float inside the tank is connected to a magnetic carrier in the indicating tube. The magnetic carrier operates magnetic roller indicators on the local level display as well as optional adjustable level switches and level transmitter. The magnetic carrier is located within the measuring tube and operates the level indicator, switches and transmitters in a non-contacting fashion
